2017 Chevrolet Silverado 1500

Vehicle

2017 Chevrolet Silverado 1500

Trim

LT

Chassis

K2XX

Drivetrain

4WD

Engine

L83 · 5.3L

Power adder

GM LT4 TVS1740

Engine

L83

Displacement

5.3L

Block

Stock

Crankshaft

Aftermarket · GM LT1

Rods & pistons

Drop-in Rod & Piston Package

Compression

10.6:1

Heads

Stock

Cam

BTR Supercharged Stage 3

Cam specs

228/25X · 0.648/0.648 lift · 113 LSA

Lifters

GM / Cadillac Racing Lifters

Valve springs

BTR Dual .660

VVT

Deleted

AFM / DFM

Deleted

Intake manifold

LT4 Supercharger

Throttle body

Katech ported LT4

Cold air intake

ADM tube and K&N housing

PCV / catch-can setup

Catch can · Motion Receworks

PCV details

Active 2 stage

Type

Supercharger

System

GM LT4 TVS1740

Subtype

Roots

Pulley

2.5

Intercooler

Air-to-Water · GM · Z06

Manifolds / headers

Long-Tube Headers · Speed Engineering

Primary size

1 7/8”

Collector size

3.5”

Catalytic converters

None / Catless

Configuration

Custom

Pipe diameter

3”

Muffler / cat-back

Flowmaster · FX

Cutouts

None

Notes

3” x-pipe to 3.5” y-collector to muffler

DI Injectors

LT4 Injectors

HPFP

LT4 HPFP

Low side

Single

Pumps

TI Automotive / Walbro 535 ×1

Hanger

Stock

Fuel style

Factory / Returnless

Transmission

6L80

Configuration

Built

Builder

ACE Performance · Beast Build

Converter / clutch

Circle D 258mm

Stall

2700 rpm

Transfer case

Factory

Rear gear

4.56:1

Rear differential

Modified Factory Housing · Factory

Front differential

Factory

Front suspension

Modified · Dirt King +3.5”, Fox 2.5 Coilover, Fox 3.0 Triple Bypass

Rear suspension

Modified · Dirt King, Fox 16x3.0” Triple Bypasses, Deavers U182, Dirt King shackle & hanger

Front brakes

Upgraded · Wilwood areo6 DM

Rear brakes

Upgraded · Powerstop Z36

Weight

6100 lb · driver Yes

Off-Road wheels

KMC · GRS · 17×9 · -12 · Square

Off-Road tires

Mickey Thompson · Baja Boss · 37x17-12.5 · Square

No results added yet.

Current Setup · Current
